This device is suitable for leak detection of Prismastic cell batteries. Manually picking and discharging materials, automatically detecting leaks and providing detection results, no alarm if OK, and an alarm if NG.

Technical parameters and configuration characteristics

1. Number of detectable workpieces 1

2. Minimum detectable leakage rate 3 × 10-13Pa · m3/s

3. Leakage rate display range: 1 × 10-1------1 × 10-13Pa · m3/s

4. Start time ≤ 100s

5. Response time ≤ 0.3 S

6. The maximum pressure at the leak detection port is 2000Pa

7. Power requirements: AC220V ± 10%/50Hz

8. Leakage rate units: Pa · m3/s, ppm, mbar · l/s, atm.cc/s

9. Display interface with a large 7.0-inch touch screen display, clear and easy to understand operation interface

10. Unqualified leakage rate setting, alarm volume setting, etc., equipped with automatic leak detection alarm, providing sound and visual prompts

11. With serial RS232 level output

12. Large capacity memory, capable of storing 10000 sets of test results

13. USB data output, which can directly write detection data to a USB drive

14. Rich input and output contacts

15. With a complete product chain and a variety of optional accessory combinations, it can meet the testing needs of different products

16. Main components imported from Europe and America: original imported molecular pump, German Leibao mechanical pump, German Baoti electromagnetic valve, American imported amplifier

Tags:

lithium ion battery making machine,

lithium ion battery machine,

lithium battery machine

Helium Mass Spectrometer Leak Detector

Contact Now

2000W/4000W Laser Welding Machine for Prismastic Cell, Cylindrical cell or battery pack

Contact Now

Power Battery Negative Pressure Forming Machine For Prismastic Cell Battery

Contact Now

5V60A-48CH Power Battery Negative Pressure Forming Machine For Prismastic Cell Battery

Contact Now

Laser Clean Machine For Prismastic Cell, Cylindrical Cell Or Battery Pack

Contact Now

PRODUCTS DETAILS

Products

Coin Cell Assembly Machine

Pouch Cell Assembly Equipment

Cylindrical Cell Assembly Machine

Battery Slurry Mixer

Battery Materials Drying Oven

Battery Coating Machine

Battery Sealing Machine

Electrode Roller Press Equipment

Electrode Slitting Cutting Equipment

Battery Cell Welding Machine

Winding Stacking Equipment

Electrochemical Workstation

Pouch Cell Forming Machine

Electrolyte Filling Injection Equipment

Battery Slurry Viscometer

Vacuum Standing Box

Pouch Cell Cutting Edge Equipment

Coin Cell Crimping Machine

Cylindrical Cell Groove Crimping Equipment

NMP Solvent Treatment System

Battery Laboratory Equipment

Battery Pilot Machine

Electrode Preparation

Prismatic Cell Assembly Machine

Battery Pack Equipment

Battery Production Line

Laboratory Glove Box

Battery Drying Room

Rotary Dehumidifier

Battery Test Equipment

Battery Materials And Accessories

Helium Mass Spectrometer Leak Detector

Payment Method:	T/T, Western Union

Detail Information

Product Description

Detail Information

Brand Name

GERUISI

Model Number

PA4001

Response Time:

≤ 0.3 S

Minimum Detectable Leakage Rate:

3 × 10-13Pa · M3/s

Payment Terms:

T/T, Western Union

Highlight

Helium mass spectrometer device

Helium mass spectrometer Detector

mass spectrometer leak detector device

Product Description

Equipment Development Overview

Technical parameters and configuration characteristics

1. Number of detectable workpieces 1

2. Minimum detectable leakage rate 3 × 10-13Pa · m3/s

3. Leakage rate display range: 1 × 10-1------1 × 10-13Pa · m3/s

4. Start time ≤ 100s

5. Response time ≤ 0.3 S

6. The maximum pressure at the leak detection port is 2000Pa

7. Power requirements: AC220V ± 10%/50Hz

8. Leakage rate units: Pa · m3/s, ppm, mbar · l/s, atm.cc/s

9. Display interface with a large 7.0-inch touch screen display, clear and easy to understand operation interface

10. Unqualified leakage rate setting, alarm volume setting, etc., equipped with automatic leak detection alarm, providing sound and visual prompts

11. With serial RS232 level output

12. Large capacity memory, capable of storing 10000 sets of test results

13. USB data output, which can directly write detection data to a USB drive

14. Rich input and output contacts

15. With a complete product chain and a variety of optional accessory combinations, it can meet the testing needs of different products

16. Main components imported from Europe and America: original imported molecular pump, German Leibao mechanical pump, German Baoti electromagnetic valve, American imported amplifier
