Laser Clean Machine For Prismastic Cell, Cylindrical Cell Or Battery Pack

Payment Method:	T/T, Western Union

Detail Information

Product Description

Detail Information

Brand Name

GERUISI

Average Laser Power:

≥100W

Output Power Instability:

<3%

Payment Terms:

T/T, Western Union

Highlight

Laser clean lithium battery machine

Prismastic lithium battery machine

Laser clean lithium ion battery manufacturing machine

Product Description

Laser cleaning machine operating environment

The basic operating environment of this product is as follows:

Content	Parameters
Supply voltage	220V AC,50Hz
Power consumption of the whole machine	0.8KW
Placement environment	Smooth, no vibration, no impact
Working environment temperature	0 ℃ ~ 40 ℃
Working environment humidity	≤80%

Laser cleaning machine mechanical parameters

Content	Parameters
Size	800mm × 630mm × 1450mm
Weight Volume	70Kg
Fiber Length	5m
Movements	Roller
Scan width	100-300mm (optional)

Laser cleaning machine optical parameters

Content	Parameters
average laser power	≥100W
Output power instability	<3%
Power adjustment range (%)	10- 100 (gradient adjustable)
Focused spot diameter (mm)	0.03
Center Wavelength (nm)	1064
Repetition frequency (KHz)	20-200 (gradient adjustable)
Cooling mode	air-cooled
